210g (6.2oz) V-Weave 2x2 Twill 3k Carbon Fiber Cloth 1500mm (59")

This amazing fabric has been developed to solve the problem of creating a cosmetic "V-Weave" type pattern on cosmetic carbon panels. This feature is seen only on the top supercars and hypercars and, until now, has been a very difficult and time consuming feature to replicate. This fabric makes achieving the desired finish much easier than before.

This specialist fabric is based on the same top quality carbon fiber fabric used in our manufacturing facility every day. This fabric uses the top quality Mitsubishi-Rayon Pyrofil TR30S 3K fibers in its manufacture. The fabric is woven into a 2x2 twill pattern with the V-Weave center line is positioned exactly in the middle of the fabric. The 1.5m (59") wide roll width has been chosen so it suits the widest range of applications and should suit even the widest of car bonnets and body panels you are likely to encounter.

Typical Uses

V-Weave carbon fiber fabric is perfect for any application where the best possible visual appearance is required with a unique visual effect that only the V-Weave pattern can provide. V-Weave only needs to be used for the visible layer of carbon fiber on a part so when making 100% carbon fiber parts you only need to use V-Weave for the 1st layer into the mold. Extra care needs to be taken during this stage to ensure that the V-Weave center line is both perfectly aligned at the center of the mold and also kept perfectly straight and distortion free to ensure the center line does not appear to wonder or look wavey. Making it the ideal carbon fiber for bonnets or carbon fiber for hoods.

How to Buy

This roll is 1.5m (59") wide and the fabric is sold by the linear meter (1 meter = 1.09 yards). The unit price shown is for 1 linear meter but volume discounts automatically apply for larger quantities of fabric.

Please purchase the number of linear meters you require. When purchasing multiple meters the fabric will be supplied in one continuous length on a roll.

Further Information

Resin Infusion

V-Weave is a great choice for resin infusion projects where you want a high grade cosmetic finish. Being woven from a top quality carbon fiber, the V-Weave fabric will wet out very well during the infusion process.

Skinning/Wrapping Parts in Carbon Fiber

If you are skinning/wrapping carbon fiber around the outside of a part (for cosmetic purposes) then V-Weave can be used for its amazing cosmetic effect to make the skinned part truly look like a high grade professionally made part.
